Code: WHASIGMAX10MKII
Enhance your audio experience with Wharfedale Sigma X10 MKII Black 10" 200w passive install speaker. Perfect for professional sound installations.
€415.00
In Stock
QtyAdd to Cart
Wharfedale Sigma X10 MKII Black -10" 200w Passive Install Speaker with Mounting Point for Powerdrive (bracket Not Included)
The Wharfedale Sigma X10 MKII is a compact yet powerful passive speaker designed for professional audio installations. With high-quality components, durable construction, and versatile mounting options, it delivers exceptional sound performance for a wide range of applications.
Key Features:
Key Features:
- Two-Way Passive System: Combines a 10" low-frequency transducer and a 1.75" titanium compression driver for balanced, dynamic audio.
- Power Handling: Handles 200W continuous, 400W program, and 800W peak power, ensuring consistent and reliable performance.
- Frequency Response: Wide frequency range of 60 Hz to 20 KHz (-10 dB) with a precise crossover at 2.4 KHz.
- High Sensitivity: 97 dB sensitivity and a maximum SPL of 126 dB for clear and powerful sound output.
- Connectivity: Features 2 speakON connectors and 1 barrier strip for flexible audio system integration.
- Durable Build: Constructed with 15 mm MDF and finished with black paint, protected by a sturdy 1.2 mm steel grille.
- Mounting Flexibility: Equipped with a dual-angle (0°/10°) 35 mm pole socket and M8 mounting points, compatible with Powerdrive brackets (bracket not included).
- Portable Design: Includes a convenient rear handle for easy transport and positioning.
- System Type: Passive
- Configuration: Two-Way
- Frequency Response (+/-3 dB): 65 Hz – 18 KHz
- Frequency Range (-10 dB): 60 Hz – 20 KHz
- Sensitivity 2.83 V / 1 m: 97 dB
- Calculated Maximum SPL @1 m: 126 dB
- System Rated Impedance: 8 Ω
- Size (mm / inches): 254 mm / 10”
- Voice Coil Size (mm / inches): 38 mm / 1.5”
- Rated Impedance: 8 Ω
- LF Power re:AES2-2012: 200 W
- HF Driver Type: Compression Driver
- Coil Size (mm / inches): 44 mm / 1.75”
- Exit Size (mm / inches): 1″
- Diaphragm Material: Titanium
- Rated Impedance: 8 Ω
- HF Power re:AES2-2012: 40 W
- Waveguide Type: Constant Directivity / Rotatable
- Nominal Coverage (H x V): 90˚ x 60˚
- LF Driver: 1 x 10″
- HF Driver: 1 x 1.75″ Titanium Compression Driver
- System Continuous Power: 200 W
- System Programme Power: 400 W
- System Peak Power: 800 W
- Crossover frequency: 2.4 KHz
- Recommended HPF = BW 18 dB/oct.: 45 Hz
- Input Connector: 2 x speakON / 1x Barrier Strip
- Dual-angle (0° /10°) 35 mm socket
- M8 x 17
- 1 handle on back
- Enclosure Material: 15 mm MDF
- Finish: Black Paint
- Grille Material & Finish: 1.2 mm steel, painted
- Height: 520 mm / 20.5″
- Width Front: 338 mm / 13.3″
- Width Rear: 213 mm / 8.4″
- Depth: 338.3 mm / 13.3″
- Height: 585 mm / 23″
- Width Front: 441 mm / 17.3″
- Width Rear: 251 mm / 9.9″
- Depth: 389 mm / 15.3″
- Net Weight: 17.1 kg / 37.62 lbs
- Gross Weight: 18.8 kg / 41.4 lbs
- WPB-1 / WPB-2
